Главная Каталог продукции Toolunited 15 303-09 - Thread end mill 80992001000015

80992001000015

Артикул: 1491110

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

8 mm

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

0 - Without coolant exit

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

3.142 mm

Delivery state valid from

4/24/2012

DIN

ZYL00601305

FamilyProducts

Gewindefräser

FHA Flute helix angle

27 Degree

FHH Flute helix hand

HAND Cutting direction

R - Right

ID Technical product number

1491110

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0060

LOC-03 DCONMS Diameter

6 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00601305

LPR Protruding length

13 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

80992001000015

OAL Overall length

49 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
