Главная Каталог продукции Toolunited 15 303-09 - Thread end mill 80273002000094

80273002000094

Артикул: 1499660

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

16.46 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

7.79 mm

Delivery state valid from

4/24/2012

DIN

ZYL01201315

FamilyProducts

Gewindefräser

FHA Flute helix angle

27 Degree

FHH Flute helix hand

R - Hand of helix right

GRDMFG Grade manufacturers designation

VHM, TiCN

HAND Cutting direction

N - Neutral

ID Technical product number

1499660

Interface codes

J6 /

ISYC Subclass

303-09 - Thread end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01201315

LPR Protruding length

29 mm

MILTTY Mill tool type ISO

T - Thread cutter

Name Identifying order number

80273002000094

OAL Overall length

74 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
