Главная Каталог продукции Toolunited 15 303-08 - Rounded profile end mill, concave 70922580040809

70922580040809

70922580040809 70922580040809

70922580040809

Komet Group
Артикул: 1500421
В наличии
В корзину
Описание
Характеристики
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
8 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ZYL02001005
FamilyProducts
Radiusfräser 8,0
FHA Flute helix angle
0 Degree
FHH Flute helix hand
N - Hand of helix neutral
GRDMFG Grade manufacturers designation
TiAlN
HAND Cutting direction
N - Neutral
ID Technical product number
1500421
Interface codes
J6 /
ISYC Subclass
303-08 - Rounded profile end mill, concave
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02001005
Name Identifying order number
70922580040809
OAL Overall length
80 mm
PRFRAD Profile radius 1
6 mm
STDNO Standard
6535HB
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
4
