50391045043400

Артикул: 1500084

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

0 mm

BD Body diameter

25 mm

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

1 - With Coolant exit, axial concentric

DC Cutting diameter

34 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

34 mm

Delivery state valid from

4/24/2012

DIN

SAK02500395

FamilyProducts

GWF KUT KF

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

H25 TiAlN

HAND Cutting direction

R - Right

ID Technical product number

1500084

Interface codes

J6 /

ISYC Subclass

303-00 - End mill unspecified

KAPR Tool cutting edge angle

45 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAK Screw mounting KOMET

LOC-03 CCUMS Connection code unit base

9 non-dimensional size with coolant

LOC-03 CZCMS Connection size code

0250

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAK02500395

LPR Protruding length

10 mm

Name Identifying order number

50391045043400

OAL Overall length

17.5 mm

PRFA Profile included angle

225 Degree

Working process

No working processes available

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
