Главная Каталог продукции Toolunited 15 303-06 - Ball-nosed end mill F4BL1000BWM20 KC637M

F4BL1000BWM20 KC637M

Артикул: F4BL1000BWM20KC637M

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

22 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

10 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/10/2007

DIN

ZYL01001005

FamilyProducts

FACT-STD-B-30°-BNOSE-RGHR-4-FL, solid carbide mill

FHA Flute helix angle

20 Degree

GRDMFG Grade manufacturers designation

KC637M

ID Technical product number

F4BL1000BWM20KC637M

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01001005

LPR Protruding length

27 mm

LS Shank length

45 mm

MILTTY Mill tool type ISO

L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°

Name Identifying order number

F4BL1000BWM20 KC637M

OAL Overall length

72 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
