Главная Каталог продукции Toolunited 15 303-06 - Ball-nosed end mill F3AW1600AWX35E320 KCPM15

F3AW1600AWX35E320 KCPM15

Артикул: 4046476

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

16 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

PVD

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

16 mm

DCONMSLD Shank diameter lower limit

0 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

5/3/2013

DIN

ZYL01600105

DN Neck diameter

15 mm

FamilyProducts

FACT-STD-35-SMOOTH-BN-3FL-XLNG, solid carbide mill

FHA Flute helix angle

35 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

35 Degree

GAMP Rake angle axial

0.1 Degree

GRDMFG Grade manufacturers designation

KCPM15

HAND Cutting direction

R - Right

ID Technical product number

4046476

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LN Neck length

32 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01600105

LPR Protruding length

32 mm

LS Shank length

118 mm

MILTTY Mill tool type ISO

K - Ball nose milling cutter (one or more then one indexable insert pro cutting edge)

Name Identifying order number

F3AW1600AWX35E320 KCPM15

OAL Overall length

150 mm

PRFRAD Profile radius 1

8 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FNU - Groove milling,FFO - Die milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
