Главная Каталог продукции Toolunited 15 303-06 - Ball-nosed end mill F2AT1200AWX30R030 KC637M

F2AT1200AWX30R030 KC637M

F2AT1200AWX30R030 KC637M

F2AT1200AWX30R030 KC637M

Kennametal
Артикул: F2AT1200AWX30R030KC637M
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
20 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
12 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/4/2011
DIN
ZYL01200105
DN Neck diameter
11 mm
FamilyProducts
FACTSTD-30°-NECKED-2FL-W/RADII, solid carbide mill
FHA Flute helix angle
30 Degree
FHH Flute helix hand
R - Hand of helix right
GAMF Rake angle radial
30 Degree
GAMP Rake angle axial
0 Degree
GRDMFG Grade manufacturers designation
KC637M
HAND Cutting direction
R - Right
ID Technical product number
F2AT1200AWX30R030KC637M
Interface codes
J6 /
ISYC Subclass
303-06 - Ball-nosed end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01200105
LPR Protruding length
63 mm
LS Shank length
45 mm
Name Identifying order number
F2AT1200AWX30R030 KC637M
OAL Overall length
110 mm
Working process
No working processes available
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
ZNC Cutting edge centre count
2
