Главная Каталог продукции Toolunited 15 303-06 - Ball-nosed end mill BNBS 2180S

BNBS 2180S

Артикул: BNBS 2180S

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

10.5 mm

BMC Body material code

D - Solid steel with soldered hard-alloy inserts (BN or DP)

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

18 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

3/21/2012

DIN

ZYL02000105

FamilyProducts

CBN-Radiusfräser BNBS 2000

FHA Flute helix angle

0 Degree

FHH Flute helix hand

N - Hand of helix neutral

GRDMFG Grade manufacturers designation

BN350

HAND Cutting direction

R - Right

ID Technical product number

BNBS 2180S

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02000105

Materials

Name Identifying order number

BNBS 2180S

OAL Overall length

130 mm

PRFRAD Profile radius 1

9 mm

Working process

FFO - Die milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
