Главная Каталог продукции Toolunited 15 303-06 - Ball-nosed end mill 78915200020805

78915200020805

Артикул: 1500404

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

10 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlTiN

COMPC Company code

KOG - Komet Group

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/24/2012

DIN

ZYL00800105

FamilyProducts

Torusfräser XH 8,0

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

30 Degree

GRDMFG Grade manufacturers designation

AlTiN

HAND Cutting direction

R - Right

ID Technical product number

1500404

Interface codes

J6 /

ISYC Subclass

303-06 - Ball-nosed end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0080

LOC-03 DCONMS Diameter

8 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00800105

LPR Protruding length

64 mm

Name Identifying order number

78915200020805

OAL Overall length

100 mm

STDNO Standard

6535HA

TCDCONMS ISO-tolerance class shank diameter

Working process

FFO - Die milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
