Главная Каталог продукции Toolunited 15 303-03 - Angular end mill (V-groove) VC2MTD0200T0500

VC2MTD0200T0500

VC2MTD0200T0500

VC2MTD0200T0500

VC2MTD0200T0500

VC2MTD0200T0500

VC2MTD0200T0500

Mitsubishi Materials

Артикул: VC2MTD0200T0500

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

6 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

VC

COMPC Company code

MI - Mitsubishi Materials

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

2 mm

DCONMSLD Shank diameter lower limit

-0.008 mm

DCONMSUD Shank diameter upper limit

0 mm

DCP Data chip provision

0 - Without data chip

DCX Cutting diameter maximum

3.05 mm

Delivery state valid from

4/1/2022

DIN

ZYL00400105

F71 Number of corner designs

1

FamilyProducts

Taper end mill,2 flute,Medium cut length

FHA Flute helix angle

30 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

30 Degree

GAMP Rake angle axial

0 Degree

GRDMFG Grade manufacturers designation

UWC

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

303-03 - Angular end mill (V-groove)

KAPR Tool cutting edge angle

85 Degree

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0040

LOC-03 DCONMS Diameter

4 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL00400105

Materials

P,H

Name Identifying order number

VC2MTD0200T0500

OAL Overall length

45 mm

TCDCONMS ISO-tolerance class shank diameter

h6

Working process

FFO - Die milling

ZEFF Face effective cutting edge count

2

ZEFP Peripheral effective cutting edge count

2

ZNC Cutting edge centre count

2
