Главная Каталог продукции Toolunited 15 303-01 - Non-centre cutting end mill F3BA0600BWS30 KC637M

F3BA0600BWS30 KC637M

F3BA0600BWS30 KC637M

F3BA0600BWS30 KC637M

Kennametal
Артикул: F3BA0600BWS30KC637M
В наличии
В корзину
Описание
Характеристики
APMX Depth of cut maximum
13 mm
BMC Body material code
H - Solid carbide
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
6 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/10/2007
DIN
ZYL00601005
F71 Number of corner designs
1
FamilyProducts
FACT-STD-B-30°-ALUM-RGHR-3-FL, solid carbide mill
FHA Flute helix angle
30 Degree
GRDMFG Grade manufacturers designation
KC637M
ID Technical product number
F3BA0600BWS30KC637M
Interface codes
J6 / J61
ISO
ZYL10F6000$$$$
ISYC Subclass
303-01 - Non-centre cutting end mill
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0060
LOC-03 DCONMS Diameter
6 mm
LOC-03 ISO
ZYL10F6000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL00601005
LPR Protruding length
18 mm
LS Shank length
39 mm
Name Identifying order number
F3BA0600BWS30 KC637M
OAL Overall length
57 mm
RE Corner radius
0.25 mm
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
3
