Главная Каталог продукции Toolunited 15 303-01 - Non-centre cutting end mill F3AD1200BDL30 KC633M

F3AD1200BDL30 KC633M

Артикул: F3AD1200BDL30KC633M

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

22 mm

BMC Body material code

H - Solid carbide

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/10/2007

DIN

ZYL01201005

F71 Number of corner designs

FamilyProducts

SC DRILL SLOT ENDMILL B

FHA Flute helix angle

30 Degree

GRD2ND Standard designation of the grade 2nd application

HC-M30

GRD3RD Standard designation of the grade 3rd application

HC-M20

GRDMFG Grade manufacturers designation

KC633M

GRDPRIO Standard designation of the grade main application

HC-P30

ID Technical product number

F3AD1200BDL30KC633M

Interface codes

J6 /

ISYC Subclass

303-01 - Non-centre cutting end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01201005

LPR Protruding length

38 mm

LS Shank length

45 mm

Name Identifying order number

F3AD1200BDL30 KC633M

OAL Overall length

83 mm

STDLET Standard letter to the standard number

Lang

STDNO Standard

DIN6527

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
