Главная Каталог продукции Toolunited 15 303-02 - Centre cutting end mill SCM570-2000Z05R-HB-HP723

SCM570-2000Z05R-HB-HP723

Артикул: 30510349

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

41 mm

BMC Body material code

H - Solid carbide

CHW Corner chamfer width

0.3 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

AlCrN

COMPC Company code

MP - Mapal

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

20 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/10/2017

DIN

ZYL02001005

F71 Number of corner designs

FamilyProducts

SCM57 OptiMill-Uni-HPC-Silent, long

FHA Flute helix angle

42 Degree

FHH Flute helix hand

R - Hand of helix right

GAMF Rake angle radial

41 Degree

GRDMFG Grade manufacturers designation

HP723

HAND Cutting direction

R - Right

ID Technical product number

30510349

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

KCH Corner chamfer angle

45 Degree

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL02001005

LPR Protruding length

55 mm

Name Identifying order number

SCM570-2000Z05R-HB-HP723

OAL Overall length

104 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FNU - Groove milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count

ZNC Cutting edge centre count
