Главная Каталог продукции Toolunited 15 303-02 - Centre cutting end mill DSFD.7.12.24.77.3.12 HD05

DSFD.7.12.24.77.3.12 HD05

Артикул: DSFD7122477312HD05

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

24 mm

BMC Body material code

D - Solid steel with soldered hard-alloy inserts (BN or DP)

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

HORN - Paul Horn

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

12 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/15/2014

DIN

ZYL01200105

DN Neck diameter

11.3 mm

F71 Number of corner designs

FamilyProducts

DSFD Multiple fluted Finishing Endmill, push

FHA Flute helix angle

3 Degree

FHH Flute helix hand

L - Hand of helix left

GAMF Rake angle radial

3 Degree

GRDMFG Grade manufacturers designation

HD05

HAND Cutting direction

R - Right

ID Technical product number

DSFD7122477312HD05

Interface codes

J6 /

ISYC Subclass

303-02 - Centre cutting end mill

LN Neck length

35 mm

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12 mm

LOC-03 TCDCONCDMS Connection tolerance class coded

h$06

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01200105

LPR Protruding length

35 mm

Materials

Name Identifying order number

DSFD.7.12.24.77.3.12 HD05

OAL Overall length

85 mm

TCDCONMS ISO-tolerance class shank diameter

Working process

FEC - Square shoulder milling,FNB - Slotting,FPL - Face milling

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
