Главная Каталог продукции Toolunited 15 405-00 - Collet unspecified 20TS090070 M100

20TS090070 M100

Артикул: 20TS090070 M100

В наличии

В корзину

Описание

Характеристики

CCFWS Connection code form

CCSWS Connection code style

CCTWS Connection code type

ZYL

CCUWS Connection code unit base

COLST Collet slot type

2 - On two side

COMPC Company code

KH - Kennametal

CZCWS Connection size code

0090

DCBN Connection bore diameter minimum

9 mm

DCBX Connection bore diameter maximum

9 mm

Delivery state valid from

10/1/2009

DFC Functional diameter

20 mm

DGUI Guide pipe diameter

27 mm

DIN

KH-Synchro 20

FamilyProducts

Sleeve for Tapping Chuck

Interface codes

J6 /

ISYC Subclass

405-00 - Collet unspecified

LOC-01 CCFWS Connection code form

LOC-01 CCSWS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-01 CCTWS Connection code type

ZYL cylindrical shank

LOC-01 CCUWS Connection code unit base

0 Metric

LOC-01 CZCWS Connection size code

0090

LOC-01-Connection-codes

J4 / J431 - Workpiece end

LOC-01-DIN

ZYL00902105

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0200

LOC-03 DCONMS Diameter

20 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

KH-Synchro 20

Name Identifying order number

20TS090070 M100

SEALP Sealing

0 - Without sealing
