Главная Каталог продукции Toolunited 14 304-12 - Sawing blade 177060 300X2,5

177060 300X2,5

Артикул: 177060 300X2,5

В наличии

В корзину

Описание

Характеристики

CDX Cutting depth maximum

90 mm

CNSC Coolant entry style code

0 - Without coolant entry

COATN Coating / Покрытие

TiN

COMPC Company code

HOG - Hoffmann Group

CWN Cutting width minimum

2.5 mm

CXSC Coolant exit style code

0 - Without coolant exit

DAH Diameter access hole

8 mm

DBC diameter bolt circle 2

55 mm

DC Cutting diameter

300 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

1/11/2017

DIN

SPK04000100

FamilyProducts

GARANT Metal circular saw blade medium

HAND Cutting direction

N - Neutral

Interface codes

J6 /

ISYC Subclass

304-12 - Sawing blade

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCSMS Connection code style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Connection code type

SPK Spindle nose mounting

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0400

LOC-03 DCONMS Diameter

40 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SPK04000100

Name Identifying order number

177060 300X2,5

NOH Mounting hole count

OAW Overall width

2.5 mm

Working process

FNU - Groove milling,FTR - Slot cutting

WT Weight of item

1.22 kg

ZEFP Peripheral effective cutting edge count

160
