50987000002022
50987000002022
Артикул:
1500198
В наличии
Характеристики
APMX Depth of cut maximum
22 mm
BD Body diameter
16 mm
BI Block index
1
CCONMS Connection count machine side
1
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KOG - Komet Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter
21.1 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DIN
ZYL02501315
DN Neck diameter
16 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
1
FamilyProducts
Gewindefräshalter-XAM
HAND Cutting direction
R - Right
ID Technical product number
1500198
Interface codes
J6 /
ISYC Subclass
307-06 - Threading end mill
LF Functional length
100 mm
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-03 CCFMS Connection code form
13
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0250
LOC-03 DCONMS Diameter
25 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02501315
LPR Protruding length
44 mm
LS Shank length
56 mm
LU Usable length
48 mm
Name Identifying order number
50987000002022
OAL Overall length
100 mm
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
1
