E90XC D20-22-C20-06
E90XC D20-22-C20-06
Артикул:
3110566
В наличии
Характеристики
APMX Depth of cut maximum
22 mm
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CICT Cutting item count
5
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
20 mm
DCP Data chip provision
0 - Without data chip
DIN
ZYL02000115
FamilyProducts
Drilling Endmills Carrying Square S/XOMT Inserts
HAND Cutting direction
R - Right
ID Technical product number
3110566
Interface codes
J6 / J61
ISO
ZYL01G2000h$06
ISYC Subclass
307-09 - Centre cutting multiple rows end mill
KAPR Tool cutting edge angle
90 Degree
LF Functional length
120 mm
LH Head length
37 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0200
LOC-03 DCONMS Diameter
20 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03 ISO
ZYL01G2000h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL02000115
LPR Protruding length
70 mm
Name Identifying order number
E90XC D20-22-C20-06
OAL Overall length
120 mm
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
0.24 kg
ZEFF Face effective cutting edge count
1
ZEFP Peripheral effective cutting edge count
1
