12292810800
12292810800
Артикул:
12292810800
В наличии
Характеристики
A1A Cutting edge angle major Pos. A
60 Degree
A2A Clearance angle major Pos. A
15 Degree
ADJBY Adjustment property
0 - Adjustment not possible
APMX Depth of cut maximum
31 mm
B3A Inscribed circle diameter Pos. A
10.4 mm
BLDA Tool style code Position A
99
C1A Insert thickness Pos. A
4.76 mm
CCONMS Connection count machine side
1
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
WI - Widia
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
32 mm
Delivery state valid from
357.1 €
DIN
MKG00401195
FamilyProducts
M 28 Ball nose end mill
HAND Cutting direction
R - Right
ID Technical product number
12292810800
Interface codes
J6 /
ISYC Subclass
307-12 - Angular ball-nosed end mill
LF Functional length
61.5 mm
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
SD0903083N
LOC-03 CCFMS Form
11
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
MKG Morse taper
LOC-03 CCUMS Unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Size code
0040
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
MKG00401195
LPR Protruding length
61.5 mm
MILTTY Mill tool type ISO
L - Face and side end mill with ball nose (more then one indexable insert pro cutting edge) 90°
Name Identifying order number
12292810800
OAL Overall length
164 mm
Working process
FRU - Round moulding
