Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill ZR252T

ZR252T

ZR252T ZR252T ZR252T

ZR252T

Mitsubishi Materials
Артикул: ZR252T
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
APMX Depth of cut maximum
6 mm
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
MI - Mitsubishi Materials
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
25 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/1/2022
DIN
ZYL03201005
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
ENDMILL
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03201005
LPR Protruding length
32 mm
MILTTY Mill tool type ISO
G - Side end mill (one or more indexable insert pro cutting edge) 90°
Name Identifying order number
ZR252T
OAL Overall length
190 mm
Working process
FFO - Die milling
ZEFP Peripheral effective cutting edge count
2
