Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill RSXF10025M12Z3

RSXF10025M12Z3

RSXF10025M12Z3

Sumitomo

Артикул: RSXF10025M12Z3

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

0 Degree

APMX Depth of cut maximum

5 mm

B1A Cutting edge length Pos. A

10 mm

B3A Inscribed circle diameter Pos. A

10 mm

BLDA Tool style code Position A

10

C1A Insert thickness Pos. A

3.97 mm

CCONMS Connection count machine side

2

CICT Cutting item count

3

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

5 mm

DC Cutting diameter

25 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/24/2021

DIN

SAD01200115

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

3

FamilyProducts

Wave Radius Mill RSXF10000M, Fine Pitch

GAMF Rake angle radial

-5 Degree

GAMP Rake angle axial

10 Degree

HAND Cutting direction

R - Right

Interface codes

J6 /

ISYC Subclass

307-01 - Non-centre cutting single row end mill

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAD Screw mounting

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0120

LOC-03 DCONMS Diameter

12.5 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAD01200115

LPR Protruding length

35 mm

LS Shank length

21 mm

Name Identifying order number

RSXF10025M12Z3

OAL Overall length

56 mm

THSZMS Connection thread nominal size machine side

M12

Working process

FFO - Die milling,FPL - Face milling

WT Weight of item

0.1 kg

ZEFF Face effective cutting edge count

3

ZEFP Peripheral effective cutting edge count

3
