Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill M4D032Z04A32LN15L110

M4D032Z04A32LN15L110

M4D032Z04A32LN15L110

M4D032Z04A32LN15L110

M4D032Z04A32LN15L110

Kennametal

Артикул: 5555608

В наличии

В корзину

Описание

Характеристики

A1A Cutting edge angle major Pos. A

90 Degree

APMX Depth of cut maximum

15.5 mm

B1A Cutting edge length Pos. A

17.01 mm

B2A Insert width Pos. A

10 mm

B3A Inscribed circle diameter Pos. A

10 mm

BLDA Tool style code Position A

4

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

6.96 mm

CCONMS Connection count machine side

1

CICT Cutting item count

4

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

KH - Kennametal

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

D1A Corner radius Pos. A

0.4 mm

D6A Wiper edge length Pos. A

2.2 mm

DC Cutting diameter

32 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

5/20/2015

DIN

ZYL03200115

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

4

FamilyProducts

Cylindrical End Mills • Mill 4-15

ID Technical product number

5555608

Interface codes

J6 /

ISYC Subclass

307-01 - Non-centre cutting single row end mill

KAPR Tool cutting edge angle

90 Degree

LH Head length

110 mm

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200115

LPR Protruding length

49 mm

Name Identifying order number

M4D032Z04A32LN15L110

RPMX Rotational speed maximum

22000 1/min

Working process

No working processes available

WT Weight of item

0.58 kg

ZEFF Face effective cutting edge count

4

ZEFP Peripheral effective cutting edge count

4
