Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill M1D075E1002CM10

M1D075E1002CM10

M1D075E1002CM10 M1D075E1002CM10 M1D075E1002CM10

M1D075E1002CM10

Kennametal
Артикул: 3742471
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DCP Data chip provision
0 - Without data chip
Delivery state valid from
11/1/2008
DIN
KH-M10
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
Indexable End Mills - Screw-On - Inch
HAND Cutting direction
R - Right
ID Technical product number
3742471
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAD Screw mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
KH-M10
Name Identifying order number
M1D075E1002CM10
RMPX Ramping angle maximum
6.5 Degree
RPMX Rotational speed maximum
45900 1/min
Working process
No working processes available
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
