Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill HM90 E90AD-D40-4-CF4

HM90 E90AD-D40-4-CF4

HM90 E90AD-D40-4-CF4 HM90 E90AD-D40-4-CF4

HM90 E90AD-D40-4-CF4

Iscar
Артикул: 3101741
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
15 Degree
APMX Depth of cut maximum
14.3 mm
B1A Cutting edge length Pos. A
15.75 mm
B2A Insert width Pos. A
9.54 mm
B3A Inscribed circle diameter Pos. A
9.54 mm
BD Body diameter
44 mm
BLDA Tool style code Position A
4
C1A Insert thickness Pos. A
5.63 mm
CCONMS Connection count machine side
1
CICT Cutting item count
4
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
1 mm
D4A Cutting edge angle major Pos. A
90 Degree
D6A Wiper edge length Pos. A
1.6 mm
DC Cutting diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2014
DIN
ICF00400115
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
4
FamilyProducts
HM90 E90AD-D40-4-CF4
HAND Cutting direction
R - Right
ID Technical product number
3101741
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ICF Iscar ClickFit
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0040
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ICF00400115
LU Usable length
44 mm
Name Identifying order number
HM90 E90AD-D40-4-CF4
RMPX Ramping angle maximum
4 Degree
Working process
No working processes available
WT Weight of item
0.57 kg
ZEFP Peripheral effective cutting edge count
4
