HM90 E90AD-D40-4-C32

HM90 E90AD-D40-4-C32

Iscar
Артикул: 3101870
В наличии
В корзину
Характеристики
APMX Depth of cut maximum
3.5 mm
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CICT Cutting item count
4
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
40 mm
DCP Data chip provision
0 - Without data chip
DIN
ZYL03200105
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
4
FamilyProducts
90° Endmills Carrying HM90 ADKT-1505... Inserts
HAND Cutting direction
R - Right
ID Technical product number
3101870
Interface codes
J6 / J61
ISO
ZYL01G3200h$06
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LF Functional length
130 mm
LH Head length
40 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03 ISO
ZYL01G3200h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03200105
LPR Protruding length
70 mm
Name Identifying order number
HM90 E90AD-D40-4-C32
OAL Overall length
130 mm
RMPX Ramping angle maximum
4 Degree
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
0.82 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
