Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill GHFC.32.R.05-06-35

GHFC.32.R.05-06-35

GHFC.32.R.05-06-35

GHFC.32.R.05-06-35

GHFC.32.R.05-06-35

Ceratizit

Артикул: GHFC.32.R.05-06-35

В наличии

В корзину

Описание

Характеристики

A2A Clearance angle major Pos. A

11 Degree

APMX Depth of cut maximum

0.8 mm

AZ Plunge depth maximum

0.5 mm

B1A Cutting edge length Pos. A

6 mm

B2A Insert width Pos. A

6 mm

B3A Inscribed circle diameter Pos. A

6.35 mm

BLDA Tool style code Position A

99

BMC Body material code

S - Solid steel

C1A Insert thickness Pos. A

2.75 mm

CCONMS Connection count machine side

1

CICT Cutting item count

5

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

CE - Ceratizit

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

32 mm

DCP Data chip provision

0 - Without data chip

DIN

SAP01600115

DN Neck diameter

17 mm

F23 Number of mounting layers

1

F24 Cutting item count per mounting layer

5

FamilyProducts

HFC high feed endmill GHFC-06

GAMF Rake angle radial

2 Degree

GAMP Rake angle axial

-2 Degree

HAND Cutting direction

R - Right

Interface codes

J6 /

ISISO A Indicator for ISO cutting plate Pos.A

1

ISYC Subclass

307-01 - Non-centre cutting single row end mill

LOC-03 CCFMS Connection code form

01

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

SAP Screw-in mounting, Ceratizit type

LOC-03 CCUMS Connection code unit base

1 Metric with coolant

LOC-03 CZCMS Connection size code

0160

LOC-03 DCONMS Diameter

16 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SAP01600115

LPR Protruding length

35 mm

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

MTP Clamping type code

S - Screwed across bore with, counter bore

Name Identifying order number

GHFC.32.R.05-06-35

RMPX Ramping angle maximum

1.3 Degree

RPMX Rotational speed maximum

22000 1/min

THSZMS Connection thread nominal size machine side

M16

Working process

FFO - Die milling,FPL - Face milling

ZEFF Face effective cutting edge count

5

ZEFP Peripheral effective cutting edge count

5
