Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill F4042.Z32.032.Z02.11

F4042.Z32.032.Z02.11

Артикул: 5403022

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

11.7 mm

BI Block index

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

W - Walter

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DC Cutting diameter

32 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DIN

ZYL03200115

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

Shoulder milling cutters F4042

HAND Cutting direction

R - Right

ID Technical product number

5403022

Interface codes

J6 / J61

ISO

ZYL01G3200$$$$

ISYC Subclass

307-01 - Non-centre cutting single row end mill

KAPR Tool cutting edge angle

90 Degree

LF Functional length

250 mm

LOC-01 BI Block index

LOC-01 ISO

WR$$AD1204**3R*****

LOC-01-Connection-codes

J44 / J441 - Insert (Unknown 01)

LOC-01-DIN

W-AD1204**

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

ZYL cylindrical shank

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 ISO

ZYL01G3200$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL03200115

LPR Protruding length

39 mm

LU Usable length

39 mm

Name Identifying order number

F4042.Z32.032.Z02.11

OAL Overall length

250 mm

RMPX Ramping angle maximum

4.19 Degree

RPMX Rotational speed maximum

10000 1/min

Working process

FEC - Square shoulder milling,FFO - Die milling,FNU - Groove milling,FPL - Face milling,FSE - Counter-sinking,FZI - Circular milling

WT Weight of item

1.5 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
