Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill E90AD D32-3-L065-HSK63-S

E90AD D32-3-L065-HSK63-S

E90AD D32-3-L065-HSK63-S E90AD D32-3-L065-HSK63-S

E90AD D32-3-L065-HSK63-S

Iscar
Артикул: 3181205
В наличии
В корзину
Описание
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CICT Cutting item count
3
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
IS - Iscar
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
32 mm
DCP Data chip provision
0 - Without data chip
DIN
HSK06300195
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
3
FamilyProducts
Adjustable Endmills (used mainly for PCD/CBN inserts)
HAND Cutting direction
R - Right
ID Technical product number
3181205
Interface codes
J6 / J61
ISO
HSK01C0630$$$$
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LH Head length
65 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
HSK Hollow taper shank
LOC-03 CCUMS Connection code unit base
9 non-dimensional size with coolant
LOC-03 CZCMS Connection size code
0630
LOC-03 DCONMS Diameter
63 mm
LOC-03 ISO
HSK01C0630$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
HSK06300195
LU Usable length
60 mm
Name Identifying order number
E90AD D32-3-L065-HSK63-S
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
28900 1/min
Working process
No working processes available
WT Weight of item
0.93 kg
ZEFF Face effective cutting edge count
3
ZEFP Peripheral effective cutting edge count
3
