Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill DAM31.411.M083.02B

DAM31.411.M083.02B

DAM31.411.M083.02B

DAM31.411.M083.02B

Paul Horn
Артикул: DAM31411M08302B
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
80 Degree
B1A Cutting edge length Pos. A
3 mm
BD Body diameter
16.9 mm
BLDA Tool style code Position A
7
C1A Insert thickness Pos. A
3.1 mm
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HORN - Paul Horn
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
10.5 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/2/2013
DIN
SAD00800115
DN Neck diameter
15.8 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
Screw-in cutter
HAND Cutting direction
R - Right
ID Technical product number
DAM31411M08302B
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAD Screw mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0080
LOC-03 DCONMS Diameter
8 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAD00800115
LU Usable length
20 mm
MILTTY Mill tool type ISO
M - Counterbore milling cutter 0°
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
DAM31.411.M083.02B
OAL Overall length
38 mm
Working process
BAB - Open by boring,FSE - Counter-sinking,FZI - Circular milling
ZEFF Face effective cutting edge count
0
ZEFP Peripheral effective cutting edge count
2
