Главная Каталог продукции Toolunited 14 307-01 - Non-centre cutting single row end mill 32E02R043M16SRD16

32E02R043M16SRD16

32E02R043M16SRD16

32E02R043M16SRD16

Kennametal
Артикул: 1888424
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
0 Degree
APMX Depth of cut maximum
8 mm
BLDA Tool style code Position A
10
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
1
CICT Cutting item count
2
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
16 mm
DCP Data chip provision
0 - Without data chip
DIN
SAD01600115
DN Neck diameter
29 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
2
FamilyProducts
Screw-On End Mills RD.X16 Inserts
ID Technical product number
1888424
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
SAD Screw mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
17 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
SAD01600115
LPR Protruding length
43 mm
Name Identifying order number
32E02R043M16SRD16
RMPX Ramping angle maximum
15 Degree
THSZMS Connection thread nominal size machine side
M16
Working process
No working processes available
WT Weight of item
0.2 kg
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
