227505 32/3
227505 32/3
Артикул:
227505 32/3
В наличии
Характеристики
A2A Clearance angle major Pos. A
15 Degree
APMX Depth of cut maximum
15.7 mm
BD Body diameter
31 mm
BLDA Tool style code Position A
5
CCONMS Connection count machine side
1
CICT Cutting item count
3
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
1 - With Coolant exit, axial concentric
DC Cutting diameter
32 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/11/2017
DIN
ZYL03201015
DN Neck diameter
32 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
3
FamilyProducts
KYOCERA 90° indexable end mill MEC17
GAMF Rake angle radial
17 Degree
GAMP Rake angle axial
-7 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-01 - Non-centre cutting single row end mill
KAPR Tool cutting edge angle
90 Degree
LH Head length
40.5 mm
LOC-03 CCFMS Connection code form
10
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03201015
LPR Protruding length
41 mm
LU Usable length
15.7 mm
Name Identifying order number
227505 32/3
OAL Overall length
100 mm
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FEC - Square shoulder milling
WT Weight of item
0.5 kg
ZEFP Peripheral effective cutting edge count
3
