F2241.W.040.Z04.09
F2241.W.040.Z04.09
Артикул:
5001052
В наличии
Характеристики
APMX Depth of cut maximum
9 mm
BMC Body material code
S - Solid steel
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
W - Walter
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DIN
ZYL03201015
F71 Number of corner designs
1
FamilyProducts
Shoulder milling cutters F2241
HAND Cutting direction
R - Right
ID Technical product number
5001052
Interface codes
J6 / J61
ISO
ZYL10G3200h$06
ISYC Subclass
303-01 - Non-centre cutting end mill
LF Functional length
110 mm
LOC-03 CCFMS Form
10
LOC-03 CCSMS Style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Type
ZYL cylindrical shank
LOC-03 CCUMS Unit base
1 Metric with coolant
LOC-03 CZCMS Size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03 TCDCONCDMS Tolerance class coded
h$06
LOC-03 ISO
ZYL10G3200h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL03201015
LPR Protruding length
49 mm
LS Shank length
60 mm
Name Identifying order number
F2241.W.040.Z04.09
OAL Overall length
110 mm
RMPX Ramping angle maximum
0 Degree
RPMX Rotational speed maximum
35700 1/min
STDLET Standard letter to the standard number
WE
STDNO Standard
ISO3338-2
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
FEC - Square shoulder milling,FNU - Groove milling,FPL - Face milling,FZI - Circular milling
WT Weight of item
0.738 kg
ZEFF Face effective cutting edge count
4
ZEFP Peripheral effective cutting edge count
4
