Главная Каталог продукции Toolunited 14 307-07 - Non-centre cutting multiple rows end mill 12293480400

12293480400

Артикул: 12293480400

В наличии

В корзину

Описание

Характеристики

ADJBY Adjustment property

0 - Adjustment not possible

APMX Depth of cut maximum

113 mm

BLDA Tool style code Position A

C1A Insert thickness Pos. A

3.18 mm

CCONMS Connection count machine side

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

WI - Widia

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

80 mm

DCP Data chip provision

0 - Without data chip

Delivery state

KA - Unknown

DIN

SKG05002085

FamilyProducts

Helical cutter without nose collar

HAND Cutting direction

R - Right

ID Technical product number

12293480400

Interface codes

J6 /

ISYC Subclass

307-07 - Non-centre cutting multiple rows end mill

KAPR Tool cutting edge angle

90 Degree

LF Functional length

162 mm

LOC-02 BI Block index

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

WI-M30-80

LOC-03 CCFMS Form

LOC-03 CCSMS Style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Type

SKG steep taper shank

LOC-03 CCUMS Unit base

8 non-dimensional size

LOC-03 CZCMS Size code

0500

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

SKG05002085

LPR Protruding length

162 mm

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

Name Identifying order number

12293480400

OAL Overall length

288.8 mm

RE Corner radius insert position A

5 mm

Working process

FWA - Hob
