SGSF 160-6-40K
SGSF 160-6-40K
Артикул:
2301018
В наличии
Характеристики
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CICT Cutting item count
10
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
IS - Iscar
CWN Cutting width minimum
5.51 mm
CWX Cutting width maximum
6.5 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
160 mm
DCP Data chip provision
0 - Without data chip
DIN
FDA04000105
FamilyProducts
Slitting Cutters Carrying Self-Clamped Inserts
HAND Cutting direction
R - Right
ID Technical product number
2301018
Interface codes
J6 / J61
ISO
FDA01G4000H$07
ISYC Subclass
308-09 - Saw blade / slitting cutter
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
40 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
H$07
LOC-03 ISO
FDA01G4000H$07
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA04000105
MILTTY Mill tool type ISO
D - Slot or separating cutter
Name Identifying order number
SGSF 160-6-40K
RPMX Rotational speed maximum
500 1/min
TCDCONMS ISO-tolerance class shank diameter
H7
Working process
No working processes available
WT Weight of item
0.55 kg
ZEFP Peripheral effective cutting edge count
10
