Главная Каталог продукции Toolunited 14 308-05 - Full-side slot milling cutter F51 22191

F51 22191

F51 22191

F51 22191

Komet Group
Артикул: 1486091
В наличии
В корзину
Описание
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KOG - Komet Group
CWX Cutting width maximum
7 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
100 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/24/2012
DHUB Hub diameter
46 mm
DIN
65568
FamilyProducts
Scheibenfräser Ø 100 b=7
HAND Cutting direction
N - Neutral
ID Technical product number
1486091
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
66918
LOC-03 CCFMS Connection code form
04
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
65568
Name Identifying order number
F51 22191
OAL Overall length
7 mm
STDNO Standard
SFT.100.004.70
Working process
No working processes available
WT Weight of item
0.2 kg
ZEFF Face effective cutting edge count
10
ZEFP Peripheral effective cutting edge count
10
