Главная Каталог продукции Toolunited 14 308-05 - Full-side slot milling cutter F4253.UBN26.102.Z05.13R

F4253.UBN26.102.Z05.13R

F4253.UBN26.102.Z05.13R

F4253.UBN26.102.Z05.13R

Walter
Артикул: 5522233
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CDX Cutting depth maximum
24 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CWN Cutting width minimum
12.7 mm
CWX Cutting width maximum
12.7 mm
CXSC Coolant exit style code
0 - Without coolant exit
DAH Diameter access hole
21 mm
DC Cutting diameter
101.6 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
47.625 mm
DIN
FDA10001220
F24 Cutting item count per mounting layer
10
FamilyProducts
Slotting cutters for ‌slot milling F4253
HAND Cutting direction
R - Right
ID Technical product number
5522233
Interface codes
J6 / J61
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISO
FDA12S1000$$$$
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-03 CCFMS Form
12
LOC-03 CCSMS Style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Type
FDA Milling arbor mounting
LOC-03 CCUMS Unit base
2 Inch
LOC-03 CZCMS Size code
1000
LOC-03 DCONMS Diameter
25.4 mm
LOC-03 ISO
FDA12S1000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA10001220
Name Identifying order number
F4253.UBN26.102.Z05.13R
OAL Overall length
50.8 mm
RPMX Rotational speed maximum
18800 1/min
Working process
FNU - Groove milling,FPL - Face milling
WT Weight of item
1.13 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
