Главная Каталог продукции Toolunited 14 308-05 - Full-side slot milling cutter F2252.B.250.Z08.19.S725

F2252.B.250.Z08.19.S725

F2252.B.250.Z08.19.S725 F2252.B.250.Z08.19.S725 F2252.B.250.Z08.19.S725 F2252.B.250.Z08.19.S725

F2252.B.250.Z08.19.S725

Walter
Артикул: 5159946
В наличии
В корзину
Описание
Характеристики
ADJBY Adjustment property
0 - Adjustment not possible
BMC Body material code
S - Solid steel
CCONMS Connection count machine side
2
CDX Cutting depth maximum
78 mm
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
W - Walter
CWN Cutting width minimum
19 mm
CWX Cutting width maximum
22 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
250 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
12/1/2023
DHUB Hub diameter
90 mm
DIN
FDA06000100
F24 Cutting item count per mounting layer
16
FamilyProducts
Slotting cutters for ‌slot milling F2252
HAND Cutting direction
N - Neutral
ID Technical product number
5159946
Interface codes
J6 / J61
ISISO A Indicator for ISO cutting plate Pos.A
0
ISISO B Indicator for ISO cutting plate Pos.B
0
ISO
FDA01G6000$$$$
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-03 CCFMS Form
01
LOC-03 CCSMS Style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Type
FDA Milling arbor mounting
LOC-03 CCUMS Unit base
0 Metric
LOC-03 CZCMS Size code
0600
LOC-03 DCONMS Diameter
60 mm
LOC-03 ISO
FDA01G6000$$$$
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA06000100
Name Identifying order number
F2252.B.250.Z08.19.S725
OAL Overall length
19 mm
RPMX Rotational speed maximum
3800 1/min
Working process
FNU - Groove milling,FPL - Face milling
WT Weight of item
5.4 kg
ZEFF Face effective cutting edge count
8
ZEFP Peripheral effective cutting edge count
8
