4.91204R333
4.91204R333
Артикул:
4.91204R333
В наличии
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
32 mm
COMPC Company code
KH - Kennametal
CWX Cutting width maximum
14 mm
DC Cutting diameter
125 mm
DCP Data chip provision
0 - Without data chip
Delivery state
LH - Stocked
DHUB Hub diameter
58 mm
DIN
KH-FWDF2 215R40
F24 Cutting item count per mounting layer
10
FamilyProducts
HALF SIDE AND FACE MILL 4.215.RH
HAND Cutting direction
R - Right
ID Technical product number
4.91204R333
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CZCMS Connection size code
0400
LOC-03 DCONMS Diameter
40 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
KH-FWDF2 215R40
Name Identifying order number
4.91204R333
OAL Overall length
24 mm
Working process
No working processes available
WT Weight of item
1.5 kg
ZEFP Peripheral effective cutting edge count
10
