200J18NS90LN12N08
200J18NS90LN12N08
Артикул:
1150527
В наличии
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
60 mm
CICT Cutting item count
18
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CWN Cutting width minimum
8 mm
CWX Cutting width maximum
9 mm
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
200 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/4/2011
DHUB Hub diameter
75 mm
DIN
KH-FWDI 90LN50
FamilyProducts
NARROW SLOTTING CUTTER 90 LN
HAND Cutting direction
N - Neutral
ID Technical product number
1150527
Interface codes
J6 /
ISYC Subclass
308-05 - Full-side slot milling cutter
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
LN1245 3N
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0500
LOC-03 DCONMS Diameter
50 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
KH-FWDI 90LN50
Name Identifying order number
200J18NS90LN12N08
OAL Overall length
12 mm
Working process
No working processes available
WT Weight of item
2 kg
ZEFP Peripheral effective cutting edge count
9
