MU332.0625.03B
MU332.0625.03B
Артикул:
MU332.0625.03B
В наличии
Характеристики
BI Block index
1
CCONMS Connection count machine side
1
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
31.7 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/15/2014
DIN
ZYL06250125
DN Neck diameter
14.3 mm
FamilyProducts
Fräserschaft Typ M332
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-04 - T-slot end mill
LF Functional length
160 mm
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
HORN-33201
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
HORN-63601
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
0625
LOC-03 DCONMS Diameter
15.875 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL06250125
LU Usable length
85 mm
Name Identifying order number
MU332.0625.03B
OAL Overall length
160 mm
Working process
No working processes available
ZEFP Peripheral effective cutting edge count
0
