Главная Каталог продукции Toolunited 14 307-04 - T-slot end mill FDN D063-08-CF4-06

FDN D063-08-CF4-06

Артикул: 3102279

В наличии

В корзину

Описание

Характеристики

APMX Depth of cut maximum

8 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

IS - Iscar

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

63 mm

DCP Data chip provision

0 - Without data chip

DIN

ICF02500185

FamilyProducts

Full Slot Flange-Type Slotting Cutters with CLICKFIT Adaptation

HAND Cutting direction

R - Right

ID Technical product number

3102279

Interface codes

J6 / J61

ISO

ICF01C0250$$$$

ISYC Subclass

307-04 - T-slot end mill

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ICF Iscar ClickFit

LOC-03 CCUMS Connection code unit base

8 non-dimensional size

LOC-03 CZCMS Connection size code

0250

LOC-03 DCONMS Diameter

44 mm

LOC-03 ISO

ICF01C0250$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ICF02500185

LU Usable length

33 mm

MILTTY Mill tool type ISO

F - T-slot end mills

Name Identifying order number

FDN D063-08-CF4-06

OAL Overall length

90 mm

Working process

No working processes available

WT Weight of item

0.51 kg

ZEFP Peripheral effective cutting edge count
