Главная Каталог продукции Toolunited 14 307-04 - T-slot end mill DM008.0010.02A

DM008.0010.02A

Артикул: DM008001002A

В наличии

В корзину

Описание

Характеристики

BI Block index

CCONMS Connection count machine side

COMPC Company code

HORN - Paul Horn

DC Cutting diameter

8 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

4/2/2013

DIN

ZYL01000105

DN Neck diameter

7.7 mm

FamilyProducts

milling shank

HAND Cutting direction

R - Right

ID Technical product number

DM008001002A

Interface codes

J6 /

ISYC Subclass

307-04 - T-slot end mill

LF Functional length

91.8 mm

LOC-01 BI Block index

LOC-01-Connection-codes

J44 / J441 - Insert (Unknown 01)

LOC-01-DIN

HORN-DM008

LOC-03 CCFMS Connection code form

LOC-03 CCSMS Connection code style

5 Shaft in machine direction or hole in workpiece direction

LOC-03 CCTMS Connection code type

ZYL cylindrical shank

LOC-03 CCUMS Connection code unit base

0 Metric

LOC-03 CZCMS Connection size code

0100

LOC-03 DCONMS Diameter

10 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

ZYL01000105

LU Usable length

21.8 mm

Name Identifying order number

DM008.0010.02A

OAL Overall length

91.8 mm

Working process

No working processes available

ZEFP Peripheral effective cutting edge count
