Главная Каталог продукции Toolunited 14 307-05 - Single row rounded end mill 212070 12

212070 12

212070 12 212070 12 212070 12

212070 12

Hoffmann Group
Артикул: 212070 12
В наличии
В корзину
Описание
Характеристики
A2A Clearance angle major Pos. A
15 Degree
APMX Depth of cut maximum
2.5 mm
BD Body diameter
9.4 mm
BLDA Tool style code Position A
10
CCONMS Connection count machine side
1
CICT Cutting item count
3
CNSC Coolant entry style code
1 - With Coolant entry, axial concentric
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
12 mm
DCP Data chip provision
0 - Without data chip
DCX Cutting diameter maximum
7 mm
Delivery state valid from
1/11/2017
DIN
ZYL01200105
DN Neck diameter
11.5 mm
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
3
FamilyProducts
GARANT Copy mill (RD..05)
GAMF Rake angle radial
0 Degree
GAMP Rake angle axial
0 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
307-05 - Single row rounded end mill
LF Functional length
75 mm
LH Head length
30 mm
LOC-03 CCFMS Connection code form
01
LOC-03 CCSMS Connection code style
5 Shaft in machine direction or hole in workpiece direction
LOC-03 CCTMS Connection code type
ZYL cylindrical shank
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0120
LOC-03 DCONMS Diameter
12 mm
LOC-03 TCDCONCDMS Connection tolerance class coded
h$06
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
ZYL01200105
LPR Protruding length
30 mm
LU Usable length
30 mm
Name Identifying order number
212070 12
OAL Overall length
75 mm
TCDCONMS ISO-tolerance class shank diameter
h6
Working process
No working processes available
WT Weight of item
0.04 kg
ZEFF Face effective cutting edge count
3
