Главная Каталог продукции Toolunited 14 308-04 - Shell milling cutter M409.0040.A16.W.10

M409.0040.A16.W.10

M409.0040.A16.W.10

M409.0040.A16.W.10

Paul Horn
Артикул: M4090040A16W10
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
43.2 mm
CICT Cutting item count
10
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
HORN - Paul Horn
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
40 mm
DCCB Counterbore diameter connection bore
16 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
4/16/2015
DHUB Hub diameter
39 mm
DIN
FDA01600200
FamilyProducts
tangential mill M409
GAMF Rake angle radial
1 Degree
GAMP Rake angle axial
1 Degree
HAND Cutting direction
R - Right
ID Technical product number
M4090040A16W10
Interface codes
J6 /
ISYC Subclass
308-04 - Shell milling cutter
LCCB Counterbore depth connection bore
11.6 mm
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
R409.093.U.08
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
HORN-R409.093.U.08
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
0 Metric
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA01600200
Name Identifying order number
M409.0040.A16.W.10
OAL Overall length
65 mm
Working process
FEC - Square shoulder milling,FPL - Face milling
ZEFF Face effective cutting edge count
2
ZEFP Peripheral effective cutting edge count
2
