Главная Каталог продукции Toolunited 14 308-04 - Shell milling cutter F4338.B32.080.Z05.63

F4338.B32.080.Z05.63

Артикул: 5677417

В наличии

В корзину

Описание

Характеристики

ADJBY Adjustment property

0 - Adjustment not possible

BD Body diameter

77.9 mm

BMC Body material code

S - Solid steel

CCONMS Connection count machine side

CDX Cutting depth maximum

1.1 mm

CICT Cutting item count

CNSC Coolant entry style code

1 - With Coolant entry, axial concentric

COMPC Company code

W - Walter

CWN Cutting width minimum

63 mm

CXSC Coolant exit style code

3 - With Coolant exit, axial and radial

DAH Diameter access hole

27 mm

DC Cutting diameter

80 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

12/1/2023

DHUB Hub diameter

77.8 mm

DIN

FDA03201210

FamilyProducts

Porcupine milling cutters F4338

HAND Cutting direction

R - Right

ID Technical product number

5677417

Interface codes

J6 / J61

ISISO A Indicator for ISO cutting plate Pos.A

ISISO B Indicator for ISO cutting plate Pos.B

ISO

FDA12G3200$$$$

ISYC Subclass

308-04 - Shell milling cutter

LOC-02 BI Block index

LOC-02 ISO

WR$$AD1807123R***12

LOC-02-Connection-codes

J44 / J441 - Insert (Unknown 02)

LOC-02-DIN

W-AD1807123R***12

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

FDA Milling arbor mounting

LOC-03 CCUMS Unit base

1 Metric with coolant

LOC-03 CZCMS Size code

0320

LOC-03 DCONMS Diameter

32 mm

LOC-03 ISO

FDA12G3200$$$$

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA03201210

MILTTY Mill tool type ISO

J - Face and side and mill (one more then one indexable insert pro cutting edeg) 90°

Name Identifying order number

F4338.B32.080.Z05.63

OAL Overall length

85 mm

RPMX Rotational speed maximum

11100 1/min

Working process

FEC - Square shoulder milling,FFO - Die milling,FNU - Groove milling,FPL - Face milling,FSE - Counter-sinking,FZI - Circular milling

WT Weight of item

1.764 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
