215579 50/5
215579 50/5
Артикул:
215579 50/5
В наличии
Характеристики
BLDA Tool style code Position A
5
CCONMS Connection count machine side
1
CDX Cutting depth maximum
20 mm
CICT Cutting item count
10
CNSC Coolant entry style code
2 - With Coolant entry, radial
COMPC Company code
HOG - Hoffmann Group
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
DC Cutting diameter
50 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
1/11/2017
DHUB Hub diameter
48.1 mm
DIN
FDA02202210
FamilyProducts
GARANT Shell end mill, 90°
GAMF Rake angle radial
13.5 Degree
GAMP Rake angle axial
-11 Degree
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
308-04 - Shell milling cutter
LOC-02 BI Block index
2
LOC-02 MIID Master insert identification
APMT1335**
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
AP1335 3R
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0220
LOC-03 DCONMS Diameter
22 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA02202210
Name Identifying order number
215579 50/5
OAL Overall length
50 mm
Working process
No working processes available
WT Weight of item
0.44 kg
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
