Главная Каталог продукции Toolunited 14 308-02 - Shoulder milling cutter SRF30R-ST

SRF30R-ST

Артикул: SRF30R-ST

В наличии

В корзину

Описание

Характеристики

CCONMS Connection count machine side

CICT Cutting item count

CNSC Coolant entry style code

0 - Without coolant entry

COMPC Company code

SU - Sumitomo

CXSC Coolant exit style code

0 - Without coolant exit

DC Cutting diameter

30 mm

DCCB Counterbore diameter connection bore

18 mm

DCP Data chip provision

0 - Without data chip

Delivery state valid from

2/24/2021

DIN

FDA02200200

F23 Number of mounting layers

F24 Cutting item count per mounting layer

FamilyProducts

SUMIDIA mill SRF for high speed milling

HAND Cutting direction

R - Right

ID Technical product number

SRF30R-ST

Interface codes

J6 /

ISYC Subclass

308-02 - Shoulder milling cutter

KAPR Tool cutting edge angle

90 Degree

LOC-03 CCFMS Form

LOC-03 CCSMS Style

0 Hole in machine direction or shaft in workpiece direction

LOC-03 CCTMS Type

FDA Milling arbor mounting

LOC-03 CCUMS Unit base

0 Metric

LOC-03 CZCMS Size code

0220

LOC-03 DCONMS Diameter

22 mm

LOC-03-Connection-codes

J6 / J61 - connection code machine end

LOC-03-DIN

FDA02200200

Name Identifying order number

SRF30R-ST

OAL Overall length

50 mm

Working process

FEC - Square shoulder milling

WT Weight of item

0.34 kg

ZEFF Face effective cutting edge count

ZEFP Peripheral effective cutting edge count
