Главная Каталог продукции Toolunited 14 308-02 - Shoulder milling cutter M4D040Z05S16LN15

M4D040Z05S16LN15

M4D040Z05S16LN15

M4D040Z05S16LN15

Kennametal
Артикул: 5555801
В наличии
В корзину
Описание
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
0 Degree
B1A Cutting edge length Pos. A
17.01 mm
B3A Inscribed circle diameter Pos. A
10 mm
BLDA Tool style code Position A
4
C1A Insert thickness Pos. A
6.96 mm
CCONMS Connection count machine side
1
CDX Cutting depth maximum
15.5 mm
CICT Cutting item count
5
CNSC Coolant entry style code
2 - With Coolant entry, radial
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
3 - With Coolant exit, axial and radial
D1A Corner radius Pos. A
0.8 mm
D6A Wiper edge length Pos. A
1.8 mm
DC Cutting diameter
40 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
5/20/2015
DHUB Hub diameter
37 mm
DIN
FDA01600210
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
5
FamilyProducts
Shell Mills • Mill 4-15
ID Technical product number
5555801
Interface codes
J6 /
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
22
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
1 Metric with coolant
LOC-03 CZCMS Connection size code
0160
LOC-03 DCONMS Diameter
16 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA01600210
Name Identifying order number
M4D040Z05S16LN15
OAL Overall length
40 mm
RPMX Rotational speed maximum
18800 1/min
Working process
No working processes available
ZEFF Face effective cutting edge count
5
ZEFP Peripheral effective cutting edge count
5
