Главная Каталог продукции Toolunited 14 308-02 - Shoulder milling cutter M1D500E1809S150L200

M1D500E1809S150L200

M1D500E1809S150L200

M1D500E1809S150L200

Kennametal
Артикул: 2267645
В наличии
В корзину
Описание
Характеристики
CCONMS Connection count machine side
1
CDX Cutting depth maximum
18.034 mm
CICT Cutting item count
9
CNSC Coolant entry style code
0 - Without coolant entry
COMPC Company code
KH - Kennametal
CXSC Coolant exit style code
0 - Without coolant exit
DC Cutting diameter
127 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
8/1/2008
DIN
FDA15000220
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
9
FamilyProducts
90°Lead Mill - Mill 1-18, inch
ID Technical product number
2267645
Interface codes
J6 /
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
90 Degree
LOC-03 CCFMS Connection code form
02
LOC-03 CCSMS Connection code style
0 Hole in machine direction or shaft in workpiece direction
LOC-03 CCTMS Connection code type
FDA Milling arbor mounting
LOC-03 CCUMS Connection code unit base
2 Inch
LOC-03 CZCMS Connection size code
1500
LOC-03 DCONMS Diameter
38.1 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
FDA15000220
MTP Clamping type code
S - Screwed across bore with, counter bore
Name Identifying order number
M1D500E1809S150L200
OAL Overall length
50.8 mm
RMPX Ramping angle maximum
1.5 Degree
RPMX Rotational speed maximum
15100 1/min
Working process
No working processes available
WT Weight of item
2.54 kg
ZEFF Face effective cutting edge count
9
ZEFP Peripheral effective cutting edge count
9
