100A08RF895SP12PCA
100A08RF895SP12PCA
Артикул:
100A08RF895SP12PCA
В наличии
Характеристики
A1A Cutting edge angle major Pos. A
90 Degree
A2A Clearance angle major Pos. A
11 Degree
B1A Cutting edge length Pos. A
12.7 mm
B2A Insert width Pos. A
12.7 mm
B3A Inscribed circle diameter Pos. A
12.7 mm
BD Body diameter
59.5 mm
BI Block index
1
BLDA Tool style code Position A
2
C1A Insert thickness Pos. A
4.76 mm
CCONMS Connection count machine side
1
COMPC Company code
KH - Kennametal
DC Cutting diameter
100 mm
DCP Data chip provision
0 - Without data chip
Delivery state valid from
M6
DIN
KH-FWEI 90SP1232
F23 Number of mounting layers
1
F24 Cutting item count per mounting layer
8
FamilyProducts
FACE MILL K-MILL SP..1204
HAND Cutting direction
R - Right
Interface codes
J6 /
ISYC Subclass
308-02 - Shoulder milling cutter
KAPR Tool cutting edge angle
89.5 Degree
LOC-01 BI Block index
1
LOC-01-Connection-codes
J44 / J441 - Insert (Unknown 01)
LOC-01-DIN
KH-WP KD SPGN1204
LOC-02 BI Block index
2
LOC-02-Connection-codes
J44 / J441 - Insert (Unknown 02)
LOC-02-DIN
KH-WP SPCN P1204
LOC-03 CZCMS Connection size code
0320
LOC-03 DCONMS Diameter
32 mm
LOC-03-Connection-codes
J6 / J61 - connection code machine end
LOC-03-DIN
KH-FWEI 90SP1232
Name Identifying order number
100A08RF895SP12PCA
OAL Overall length
50 mm
Working process
No working processes available
WT Weight of item
2.5 kg
ZEFP Peripheral effective cutting edge count
8
